Are the wheel pattern and offset on the Telluride the same as the Sorento?

[Mike]

Looking to see if they are interchangeable.



[utmeep]

EX Specs based off manual measurements
Bolt pattern 5x114.3 or 5x4.5
Wheel size 18x7.5
Backspace 6.125"
Offset +48



[James]

EX Specs based off manual measurements
Bolt pattern 5x114.3 or 5x4.5
Wheel size 18x7.5
Backspace 6.125"
Offset +48

Thanks!



[CaptinKia]

great post, i assume the offset and width is the same for 20”?



[Krug]

Offset is 49.5 on the 18x7.5 wheels.



[Cherieb7229]

I want to put 20's on my EX, what specs do I need to look for?
Bolt pattern 5x114.3 or 5x4.5
Wheel size 20 x ?
Backspace ?
Offset ?
Hub bore: ?



[utmeep]

I want to put 20's on my EX, what specs do I need to look for?
Bolt pattern 5x114.3 or 5x4.5
Wheel size 20 x ?
Backspace ?
Offset ?
Hub bore: ?

https://www.discounttiredirect.com/ and select 20" wheels for the Telluride. You'll find that the offsets will average around +40 depending on how wide you go. OEM bore hub is 67.1, most aftermarket bore hubs are larger to be a universal fit. You'll need hubcentric rings.
